C-UAS Systems

Sentinel Catch

Skysec’s Sentinel Catch is actively powered by an electric motor and is capable of speeds up to 230 km/h and a range of up to 5 kilometers. With an intelligent seeker head in the nose cone only a rough 3D position of the target has to be provided to the sentinel. This can be achieved by a radar, visual-spotter or any other drone detection system which fullfills the minimum precision requirement. The intelligent flightcontroller not only can intercept moving targets but also fly complex customized flightplans like take-off, cruise, terrain follow, object avoiding, fly to safezone and more. This gives the operator the tools to secure even complex terrain with maximum protection and security.

Range:
5 km
Speed:
65 m/s
Propulsion:
electric
Payload
net & parachute
Length:
700 mm
Wingspan:
300 mm
Weight:
1.8 kg
  • modular design allows upgrade to  laser- or TV-guided mode
  • multiple flight modes like takeoff, cruise and interception for maximum planning, control and awareness
  • missions can be aborted anytime at either the current position or at a defined safe zone
  • parachute brings intercepted target and effector safely to the ground to get minimal collateral damage

Sentinel Catch&Carry

Skysec’s Sentinel Catch&Carry is actively powered by four electric motors and is capable of speeds up to 126 km/h with a range of up to 2 kilometers. It is equipped with the same seeker head as the Sentinel Catch and has the same interception workflow. Contrary to the Sentinel Catch the Sentinel Catch&Carry, as the name suggests, not only catches the target but is also able to carry it to a predefined drop zone.

Range:
2 km
Speed:
65 m/s
Propulsion:
electric
Payload
net & hook 6 kg
Length:
700 mm
Wingspan:
750 mm
Weight:
8 kg
  • modular design allows upgrade to  laser- or TV-guided mode
  • multiple flight modes like takeoff, cruise and interception for maximum planning, control and awareness
  • missions can be aborted anytime at either the current position or at a defined safe zone
  • target can be caught and carried away to a defined drop zone   to minimize possible collateral damage below interception
anchor

Scenario Examples

Airport Defence

Urban Defence
